Descriere
Omada 4G+Cat6 AX3000 Outdoor/Indoor Gateway PORT: 3× Gigabit WAN/LAN Port, 1 Nano SIM slot(4G+ Cat6) SPEC: 802.3bt/at/af，1 Ports PoE IN(support 802.3bt), 2 Ports with 45W PoE Power SPEED: 574Mbps at 2.4 GHz + 2402 Mbps at 5 GHz (HE160) Wi-Fi Speed, 300 Mbps Download LTE Speed FEATURE: Integration with Omada SDN Controller, Omada APP, Support SSL VPN, OpenVPN and Wireguard/ IPsec/ PPTP/ L2TP/ L2TP over IPSec VPN, 4G+ Cat6 LTE, 2× Detachable LTE Antennas, 160MHz Supported, OFDMA, MU-MIMO, Beamforming, Load Balance, Link Backup, Policy-based Firewall, Static Routing, Policy Routing, Multi-net DHCP, VLAN, stateful ACL, mDNS Repeater, Bridge VLAN, IP55 Weatherproof
Caracteristici
Additional-slot:
- Slot-LAN/WAN
Adsl:
- No
All Services Ready Time:
- 3.8 s
Antenna Gain Level (max):
- 4 dBi
Antenna Type:
- External
Antennas Quantity:
- 2
Brand:
- TP-LINK
Certification:
- CE, FCC, RoHS
Control Display Unit:
- No
Data Network:
- LTE
Dc-in Jack:
- Yes
Depth:
- 100.4 mm
Dhcp Server:
- Yes
Downlink/uplink Speed:
- 300/50 Mbit/s
Ethernet Lan Data Rates:
- 10,100,1000 Mbit/s
Flash Memory:
- 256 MB
Forwarding Rate:
- 1453489 Mpps
Frequency Band:
- 2.4/5 GHz
Gsm Bands Supported:
- 850,900,1800,2100 MHz
Height:
- 38.7 mm
Internal Memory:
- 512 MB
Internal Memory Type:
- DDR4
Lan-port-type:
- Gigabit
Lan-ports:
- 4
Led Indicators:
- Status
Mac Address Filtering:
- Yes
Mobile Network Generation:
- 4G
Mounting Type:
- Wall mounting
Networking Standards:
- IEEE 802.3at, IEEE 802.3bt
Operating Relative Humidity (h-h):
- 5 - 95%
Operating Temperature (t-t):
- -30 - 60 °C
Power Consumption (max):
- 16.6 W
Power Over Ethernet (poe):
- Yes
Pptp/l2tp Vpn Tunnels (max):
- 50
Product Colour:
- White
Redundant-psu:
- No
Security Algorithms:
- SSID, WPA2, WPA3
Short Message Service (sms):
- Yes
Sim Card Slot:
- Yes
Sim Card Type:
- NanoSIM
Ssl Vpn Throughput:
- 0.0866 Gbit/s
Ssl Vpn Tunnels (max):
- 50
Storage Relative Humidity (h-h):
- 5 - 90%
Storage Temperature (t-t):
- -40 - 70 °C
Wan-port-type:
- Gigabit
Wan-ports:
- 2
Web-based Management:
- Yes
Wi-fi:
- Yes
Width:
- 174 mm
